Copper Brazed Heat Exchanger
Product Overview
Copper brazed heat exchangers are compact, high-efficiency thermal transfer units designed for demanding mechanical and industrial environments. Stainless steel plates are vacuum brazed with copper to create a sealed, gasket-free structure capable of handling high pressure and temperature.
This design delivers excellent heat transfer performance within a compact footprint, making these exchangers widely used in HVAC systems, refrigeration equipment, hydraulic oil cooling, heat pumps, and industrial process cooling.
Kinetix FabWorks supplies copper brazed heat exchangers engineered for reliable performance across New Zealand and international industrial sectors.
Key Product Features
| Feature | Description |
|---|---|
| High Thermal Efficiency | Corrugated stainless steel plates create turbulence that maximizes heat transfer between fluid channels. |
| Compact Design | Plate construction enables high heat transfer performance within a small installation space. |
| Copper Brazed Structure | Vacuum brazing bonds plates without gaskets, providing a strong and leak-free unit. |
| High Pressure Capability | Designed to withstand demanding industrial pressure and temperature conditions. |
| Maintenance Free | Fully sealed structure eliminates gasket wear and reduces maintenance requirements. |
Typical Applications
| Industry | Application |
|---|---|
| HVAC Systems | Heat transfer for chillers, heat pumps, and air conditioning units |
| Refrigeration | Evaporators and condensers in commercial refrigeration |
| Hydraulic Systems | Cooling hydraulic oil in heavy industrial machinery |
| Industrial Processing | Temperature control in manufacturing processes |
| Renewable Energy | Heat recovery and geothermal systems |
Technical Specifications
| Specification | Details |
|---|---|
| Plate Material | Stainless Steel AISI 316L |
| Brazing Material | High Purity Copper |
| Maximum Pressure | Up to 30 bar (model dependent) |
| Operating Temperature | -196°C to 200°C |
| Construction | Vacuum brazed plate structure |
| Heat Transfer Surface | Multiple plate configurations available |
Connection Options
| Connection Type | Description |
|---|---|
| Threaded | Standard threaded pipe connections |
| Soldered | Copper solder connections for refrigeration systems |
| Custom Connections | Custom connection types available upon request |
Performance Advantages
| Advantage | Benefit |
|---|---|
| High Thermal Conductivity | Efficient heat transfer between fluids |
| Compact Footprint | Ideal for systems with limited installation space |
| Durable Construction | Resistant to pressure fluctuations and vibration |
| Energy Efficient | Improves system efficiency and reduces operating costs |
| Long Service Life | Brazed plate structure increases durability |
Industries Served
Industrial Manufacturing
HVAC Engineering
Food Processing Equipment
Marine Cooling Systems
Renewable Energy Installations
Hydraulic Equipment Manufacturing
Engineering Support
Kinetix FabWorks provides engineering assistance to ensure the correct heat exchanger configuration for each system.
Support includes
| Engineering Service | Description |
|---|---|
| Thermal Performance Selection | Determining correct heat transfer capacity |
| Capacity Sizing | Selecting appropriate plate configuration |
| Flow Configuration | Optimizing inlet and outlet flow paths |
| System Integration | Assisting with installation into existing systems |
Request a Quote
For copper brazed heat exchanger specifications, sizing assistance, or custom configurations, contact the Kinetix FabWorks engineering team.
Submit your technical drawings or system requirements and our team will recommend the optimal heat exchanger solution.
